Dahua HDCVI 2.0MP Bullet 2.8mm Duall Illumination HFW1200RL-IL-A-0280B-S6
In order to use the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.
- Max. 30 fps@1080p.
- 3D NR.
- Smart Light+.
- Smart Dual Light.
- 30 m illumination distance.
- Super Adapt.
- Built-in Mic.
- 2.8 mm fixed lens
- CVI/CVBS/AHD/TVI switchable.
- IP67, 12 VDC.
Specifications
Camera
- Image Sensor : 2 MP CMOS
- Max. Resolution : 1920 (H) × 1080 (V)
- Scanning System : Progressive
- Electronic Shutter Speed : PAL: 1/25 s–1/100,000 s / NTSC: 1/30 s–1/100,000 s
- Min. Illumination : 0.01 lux@F2.0 (Color, 30 IRE) / 0.001 lux@F2.0 (B/W, 30 IRE) / 0 lux (Illuminator on)
- S/N Ratio : >65 dB
- Illumination Distance : IR: 30 m (98.43 ft / Warm light: 30 m (98.43 ft)
- Illuminator On/Off Control : Auto/Manual
- Illuminator Number : 2 (Multi-core light)
Lens
- Lens Type : Fixed-focal
- Lens Mount : M12
- Focal Length : 2.8 mm
- Max. Aperture : F2.0
- Field of View : 2.8 mm: H: 102°; V: 60°; D: 129°
- Iris Control : Fixed
- Close Focus Distance
- 2.8 mm: 0.5 m (1.64 ft)
- Video Frame Rate : CVI:/PAL: 1080p@25 fps;/NTSC: 1080p@30 fps;
- AHD:PAL: 1080p@25 fps;/NTSC: 1080p@30 fps;/TVI:/PAL: 1080p@25 fps;/NTSC: 1080p@30 fps;/CVBS:/PAL: 960H;/NTSC: 960H
- Resolution/1080p (1920 × 1080); 960H (960 × 576/960 × 480)
- Day/Night : Auto(ICR)/Color/B/W
- BLC : BLC; HLC; DWDR
- WDR : DWDR
- White Balance : Auto;Area white balance
- Gain Control : Auto/Manual
- Noise Reduction : 3D NR
- Illumination Mode : Smart IR&WL (CVI, TVI); WL Mode; IR Mode
- Mirror : Yes
- Privacy Masking : Off/On (8 areas, rectangle)
Certification
- Certifications : CE-LVD: EN 62368-1; / CE-EMC: EN 55032; EN 55035;
Audio
- Built-in Mic : Yes
- Camera Audio : CVI; TVI
- Pick-up Distance : 8 m (26.25 ft)
Port
- Video Output : Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
- Power Supply : 12 VDC (±30%)
- Power Consumption : Max 2.6 W (12 VDC, IR on)
Environment
- Operating Temperature : –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity : <95% (RH), non-condensing
- Storage Temperature : –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity : <95% (RH), non-condensing
- Protection : IP67
- Anti-corrosion Level : Basic Protection
Structure
- Casing Material : Plastic
- Product Dimensions : 161.6 mm × 69.7 mm × 70.0 mm (6.36" × 2.74" × 2.76") (L × W × H)
- Net Weight : 0.17 kg (0.37 lb)
- Gross Weight : 0.26 kg (0.57 lb)
- Installation : Wall mount; ceiling mount; vertical pole mount
