Name: ASUS Prime AP201 Micro-ATX Case - Mesh Panels, USB-C, Black
SKU: 27917
Price: 109.0 EUR

Compact Micro-ATX case with quasi-filter mesh panels, tool-free side panels, 32 mm cable-management space, front USB-C and support for graphics cards up to 338 mm.

Key features

Support GPU up to 338mm in length
Quasi-filter mesh panels
Industry-leading spatial efficiency
Tool-free side panels
32 mm wide cable-management
Front panel USB Type-C® support

Specifications

Motherboard Support	Mini-ITX Micro-ATX
Drive Bays	3 x 2.5"/3.5" Combo Bay 1 x 2.5" Bay
Expansion Slots	4
Front I/O Port	1 x USB 3.2 Gen2 Type C 2 x USB 3.2 Gen1 1 x Microphone 1 x Headphone
Radiator Support (Top)	360 mm 280 mm 240 mm 140 mm 120 mm
Radiator Support (Rear)	120 mm
Cooling Support (Top)	2 x 140 mm 3 x 120 mm
Cooling Support (Rear)	1 x 120 mm
Pre-installed Fans (Front)	None
Pre-installed Fans (Rear)	1 x 120 mm
Maximum CPU Cooler Height	170 mm
Maximum GPU Length	338 mm
Maximum PSU Length	140-180 mm
Removable Dust Filters	Bottom
Maximum Cable Management Space	32 mm
Dimensions	205 x 350 x 460 mm
Weight	5.8 Kg (Mesh Edition) 6.3 Kg (Tempered Glass Edition)

Specifications from the official ASUS product page. Specifications and appearance may vary by region.

Description

Compact Micro-ATX case with quasi-filter mesh panels, tool-free side panels, 32 mm cable-management space, front USB-C and support for graphics cards up to 338 mm.

Key features

Support GPU up to 338mm in length
Quasi-filter mesh panels
Industry-leading spatial efficiency
Tool-free side panels
32 mm wide cable-management
Front panel USB Type-C® support

Specifications

Motherboard Support	Mini-ITX Micro-ATX
Drive Bays	3 x 2.5"/3.5" Combo Bay 1 x 2.5" Bay
Expansion Slots	4
Front I/O Port	1 x USB 3.2 Gen2 Type C 2 x USB 3.2 Gen1 1 x Microphone 1 x Headphone
Radiator Support (Top)	360 mm 280 mm 240 mm 140 mm 120 mm
Radiator Support (Rear)	120 mm
Cooling Support (Top)	2 x 140 mm 3 x 120 mm
Cooling Support (Rear)	1 x 120 mm
Pre-installed Fans (Front)	None
Pre-installed Fans (Rear)	1 x 120 mm
Maximum CPU Cooler Height	170 mm
Maximum GPU Length	338 mm
Maximum PSU Length	140-180 mm
Removable Dust Filters	Bottom
Maximum Cable Management Space	32 mm
Dimensions	205 x 350 x 460 mm
Weight	5.8 Kg (Mesh Edition) 6.3 Kg (Tempered Glass Edition)

Specifications from the official ASUS product page. Specifications and appearance may vary by region.
