Zudsec Electric Bolt Lock ZDL-200T
-
Lock Type
-
Product Type
NC lock = Normally Closed No power → unlocked Power ON → locks NC = Needs power to stay closed Superier low temperature, Time delay design Lower power consumption, Enviromental protection Auto-relock if no Action within 5 secs Door status signal output contact (NC/NC/COM) Safe & durable Working Measure: power-on to lock Suitable for: Wooden Door,Glass Door,Metal Door,Fire Proof Door 2 Wire with Low Temperature & Time Delay Input Voltage: DC12V Working Current: 900mA; Static Current: 100mA Working Measure: Fail safe, Locked when powered oon. Fail-safe type:: Power to lock Coil type: Continuous working Solid Bolt: polishing housing, 800Kg Holding Force Surface Temp: Low Temperature Induction Distance:8mm Dimension: Face Plate: 205Lx35WX40H(mm) / Strike: 90Lx25Wx2H(mm) / Bolt diameter: 16mm; Bolt length: 16mm Operating temp: -10~+25℃（14-131F） Operating Humidity: 0~90% Special Designed: Tested to 500000 cycles Face place material：High Aluminum, Carrulous Line Finished
Specifications:
Lock Type: Electric Bolt
Product Type: Lock
Description
NC lock = Normally Closed No power → unlocked Power ON → locks NC = Needs power to stay closed Superier low temperature, Time delay design Lower power consumption, Enviromental protection Auto-relock if no Action within 5 secs Door status signal output contact (NC/NC/COM) Safe & durable Working Measure: power-on to lock Suitable for: Wooden Door,Glass Door,Metal Door,Fire Proof Door 2 Wire with Low Temperature & Time Delay Input Voltage: DC12V Working Current: 900mA; Static Current: 100mA Working Measure: Fail safe, Locked when powered oon. Fail-safe type:: Power to lock Coil type: Continuous working Solid Bolt: polishing housing, 800Kg Holding Force Surface Temp: Low Temperature Induction Distance:8mm Dimension: Face Plate: 205Lx35WX40H(mm) / Strike: 90Lx25Wx2H(mm) / Bolt diameter: 16mm; Bolt length: 16mm Operating temp: -10~+25℃（14-131F） Operating Humidity: 0~90% Special Designed: Tested to 500000 cycles Face place material：High Aluminum, Carrulous Line Finished
Specifications:
Lock Type: Electric Bolt
Product Type: Lock
Specifications
| Lock Type | Electric Bolt |
| Product Type | Lock |
