Mechanical
- Dimensions 137 x 84 x 34 mm (5.4 x 3.3 x 1.3")
- Weight 173 g (6.1 oz)
- Enclosure material UV-stabilized polycarbonate
- Mount material Polycarbonate, SGCC steel, plastic
- Pole mount diameter 1~2" on pipe outer diameter
- Wind survivability 33.2 N at 200 km/h (7.5 lbf at 125 mph)
- Weatherproofing IPX6
Hardware
- Networking interface (1) GbE RJ45 port
- Management interface Ethernet
- Power method PoE
- Power supply UniFi PoE Switch
- Supported voltage range 44—57V DC
- Max. power consumption 8W
- Max. TX power
- 2.4 GHz
- 5 GHz
- 6 GHz
- 20 dBm
- 20 dBm
- –
- MIMO
- 2.4 GHz
- 5 GHz
- 6 GHz
- 2 x 2 (DL MU-MIMO)
- 2 x 2 (DL MU-MIMO)
- –
- Max. data rate
- 2.4 GHz
- 5 GHz
- 6 GHz
- 300 Mbps (BW40)
- 866.7 Mbps (BW80)
- –
- Antenna gain
- 2.4 GHz
- 5 GHz
- 6 GHz
- 4.7 dBi
- 6.1 dBi
- –
- Antenna (1) Internal antenna
- (2) RP-SMA connectors for optional external antennas
- LEDs (1) Power: white/blue
- (4) Mesh signal: blue
- Button Factory reset
- Mounting Wall, ceiling, pole (Included)
- Ambient operating temperature -40 to 60° C (-40 to 140° F)
- Ambient operating humidity 5 to 95% noncondensing
- Certifications CE, FCC, IC
Software
- WiFi standards 802.11a/b/g/n/ac
- Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
- BSSID 8 per radio
- VLAN 802.1Q
- Advanced QoS Per-user rate limiting
- Guest traffic isolation Supported
- Concurrent clients 200+
- Supported Data Rates
- 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b 1, 2, 5.5, 11 Mbps
- 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
- 802.11ac 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
Application Requirements
- UniFi Network Web: Version 8.0.7 and later
- iOS™: Version 10.11.1 and later
- Android™: Version 10.10.1 and later
